 ◎ Magnetic Contactor
● Possible to connect directly with electronic overcurrent relay(DPR) and thermal overload relay
● Common use of accessories
● Screw & DIN rail mounting available
● Followed IEC 60947
● Certificated CE & TUV
◎ Electronic contactors for machinery and tools
● Rated Setting:22AF~40AF
● Screw& DIN Rail mounting available
● IEC 60947 followed
● Designed to prevent to enter dusts
construction by entering dusts and impurities
| DO |
|
C |
|
9 |
|
R |
|
AC220V |
|
|
|
|
|
| Rated current(AC440V) |
| 9 |
7A |
| 12 |
9A |
| 18 |
13A |
| 22 |
20A |
| 32 |
25A |
| 40 |
32A |
| 48 |
35A |
| 50 |
48A |
| 65 |
65A |
| 75 |
75A |
| 85 |
80A | | |
|
| Main contact |
Pole |
| - |
Standard type |
| R |
Reverse Type |
| W |
High injection type(Steel case) | | |
|
| Operating current |
| AC 24-550V | | |
| Model |
DOC 32 |
DOC 40 |
DOC 48 |
| Conducting current on level AC1 |
50A |
60A |
70A |
| IEC 60947 |
AC on level 3 |
200-220V |
7.5kW 32A |
11kW 40A |
11kW 48A |
| 380-440V |
15kW 32A |
18.5kW 40A |
18.5kW 45A |
| 500-550V |
18.5kW 28A |
22kW 32A |
22kW 40A |
| 690V |
18.5kW 20A |
22kW 23A |
22kW 25A |
| Endurance |
Electrical |
1M |
1M |
1M |
| Mechanical |
12M |
12M |
12M |
| Aux. contact(Standard) |
2a2b |
2a2b |
2a2b |
Additional
Aux. contact |
Side-on |
DU-1 |
| Head-on |
DU-2, DU-4 |
| Mounting |
Screw, DIN rail |
| Dimension(mm) [WXHXD] |
68 X 82 X94.5 |
| Mounting Dimension (mm) [widthXheight] |
30~35 X 48~59 |
| 35X60 |
35X60 |
35X60 |
| Application model |
Magnetic Contactor |
Reversing type |
DOC-32R |
DOC-40R |
DOC-48R |
| Magnetic switch |
Standard type |
DOC-32 |
DOC-40 |
DOC-48 |
| Thermal Overload Relay |
Standard type(3-Elements) |
DOR-40N/3 |
DOR-40N/3 |
DOR-40N/3 |
| Model |
DOC 50 |
DOC 65 |
| Conducting current on level AC1 |
80A |
100A |
| IEC 60947 |
AC on level 3 |
200-220V |
15kW 55A |
18.5kW 65A |
| 380-440V |
22kW 50A |
30kW 65A |
| 500-550V |
30kW 43A |
33kW 60A |
| 690V |
30kW 28A |
33kW 35A |
| Endurance |
Electrical |
1M |
1M |
| Mechanical |
12M |
12M |
| Aux. contact(Standard) |
2a2b |
2a2b |
Additional
Aux. contact |
Side-on |
DU-1 |
| Head-on |
DU-2, DU-4 |
| Mounting |
Screw, DIN rail |
| Dimension(mm) [WXHXD] |
94 X 123.5 X 117.4 |
| Mounting Dimension (mm) [widthXheight] |
100 X 50~60 |
| 100X60 |
100X60 |
| Application model |
Magnetic Contactor |
Reversing type |
DOC-50R |
DOC-65R |
| Magnetic switch |
Standard type |
DOS-50 |
DOS-65 |
| Thermal Overload Relay |
Standard type(3-Elements) |
DOR-85N/3 |
DOR-85N/3 |
| Model |
DOC 75 |
DOC 85 |
| Conducting current on level AC1 |
110A |
135A |
| IEC 60947 |
AC on level 3 |
200-220V |
22kW 75A |
25kW 85A |
| 380-440V |
37kW 75A |
45kW 85A |
| 500-550V |
37kW 64A |
45kW 75A |
| 690V |
37kW 42A |
45kW 45A |
| Endurance |
Electrical |
1M |
1M |
| Mechanical |
12M |
12M |
| Aux. contact(Standard) |
2a2b |
2a2b |
Additional
Aux. contact |
Side-on |
DU-1 |
| Head-on |
DU-2, DU-4 |
| Mounting |
Screw, DIN rail |
| Dimension(mm) [WXHXD] |
94 X 123.5 X 117.4 |
| Mounting Dimension (mm) [widthXheight] |
100 X 50~60 |
| 100X60 |
100X60 |
| Application model |
Magnetic Contactor |
Reversing type |
DOC-75R |
DOC-85R |
| Magnetic switch |
Standard type |
DOS-75 |
DOS-85 |
| Thermal Overload Relay |
Standard type(3-Elements) |
DOR-85N/3 |
DOR-85N/3 |
|
